產品介紹：
-
楔型直通耐張線夾，對OPGW光纜起到保護和提高抗震作用。楔型直通耐張線夾耐酸堿耐腐蝕，壽命長，握力大，易操作，不需要配備專業工具，完全手工操作
| 標稱截面鉛/剛mm2 | 結構根數/直徑mm | 計算截面mm2 | 外徑mm | 計算拉斷力N | | 鉛 | 鋼 | 鉛 | 鋼 | 總計 | | NZX-35/6 | 6/2.72 | 1/2.72 | 34.86 | 5.81 | 40.67 | 8.16 | 12630 | | NZX-50/8 | 6/3.20 | 1/3.2 | 48.25 | 8.04 | 56.29 | 9.6 | 16870 | | NZX-50/30 | 12/2.32 | 7/2.32 | 50.73 | 29.59 | 80.32 | 11.6 | 42620 | | NZX-70/10 | 6/3.80 | 1/3.80 | 68.05 | 11.34 | 79.39 | 11.4 | 23390 | | NZX-70/40 | 12/2.72 | 7/2.72 | 69.73 | 40.67 | 110.40 | 13.6 | 58300 | | NZX-95/15 | 26/2.15 | 7/1.67 | 94.39 | 15.33 | 109.72 | 13.61 | 35000 | | NZX-95/20 | 7/4.16 | 7/1.85 | 95.14 | 18.82 | 113.96 | 13.87 | 37200 | | NZX-95/55 | 12/3.21 | 7/3.20 | 96.51 | 56.30 | 152.81 | 16.00 | 78110 | | NZX-120/7 | 18/2.90 | 1/2.90 | 118.89 | 6.61 | 125.50 | 14.50 | 27570 | | NZX-120/20 | 26/2.38 | 7/1.85 | 115.67 | 18.82 | 134.49 | 15.07 | 41000 | | NZX-120/25 | 7/4.72 | 7/2.10 | 122.48 | 24.25 | 149.73 | 15.74 | 47880 | | NZX-120/70 | 12/3.60 | 7/3.60 | 122.15 | 71.25 | 193.4 | 18.00 | 98370 | | NZX-150/8 | 18/3.20 | 1/3.20 | 144.75 | 8.04 | 152.8 | 16.00 | 32860 | | NZX-150/20 | 24/2.78 | 7/1.85 | 145.68 | 18.82 | 164.5 | 16.76 | 46630 | | NZX-150/25 | 26/2.70 | 7/2.10 | 148.86 | 24.25 | 173.11 | 17.10 | 54110 | | NZX-150/35 | 30/2.50 | 7/2.50 | 147.26 | 34.36 | 181.62 | 17.50 | 65020 | | NZX-185/10 | 18/3.60 | 1/3.60 | 183.22 | 10.18 | 193.4 | 18.00 | 40880 | | NZX-185/25 | 24/3.15 | 7/2.10 | 187.14 | 24.25 | 211.29 | 18.90 | 59420 | | NZX-185/30 | 26/2.98 | 7/2.32 | 181.34 | 29.59 | 210.93 | 18.88 | 64320 | | NZX-185/45 | 30/2.80 | 7/2.80 | 184.73 | 43.10 | 227.83 | 19.60 | 80190 | | NZX-210/10 | 18/3.80 | 1/3.80 | 204.14 | 11.34 | 215.48 | 19.00 | 45140 | | NZX-210/25 | 24/3.33 | 7/2.22 | 209.02 | 27.10 | 236.12 | 19.98 | 65990 | | NZX-210/35 | 26/3.22 | 7/2.50 | 211.73 | 34.36 | 246.09 | 20.38 | 74250 | | NZX-210/50 | 30/2.98 | 7/2.98 | 209.24 | 48.82 | 258.06 | 20.86 | 90830 | | NZX-240/30 | 24/3.60 | 7/2.40 | 244.29 | 31.67 | 275.96 | 21.60 | 75620 | | NZX-240/40 | 26/3.42 | 7/2.66 | 238.85 | 38.90 | 277.75 | 21.66 | 83370 | | 注：型號中字母與數字意義; N-耐張線夾 ; Z-直通; X-楔形; |
|
|
