產品介紹：
-
楔型直通耐張線夾，對OPGW光纜起到保護和提高抗震作用。楔型直通耐張線夾耐酸堿耐腐蝕，壽命長，握力大，易操作，不需要配備專業工具，完全手工操作
| 標稱截面鉛/剛mm2 | 規格號 | 鋼比/% | 計算/mm2 | 單線根數 | 單線直徑/mm | 直徑/mm | 額定拉斷力/KN |
|
| 鋁 | 鋼 | 總計 | 鋁 | 鋼 | 鋁 | 鋼 | 鋼芯 | 絞線 | JL/G1A | JL/G1B | JL/G2A | JL/G2B | JL/G3A | | NZX-16/3 | 16 | 17 | 16 | 2.67 | 18.7 | 6 | 1 | 1.84 | 1.84 | 1.84 | 1.84 | 6.08 | 5.89 | 5.89 | 6.45 | 6.27 | | NZX-25/4 | 25 | 17 | 25 | 4.17 | 29.2 | 6 | 1 | 2.3 | 2.3 | 2.3 | 2.3 | 9.13 | 8.83 | 8.83 | 9.71 | 9.42 | | NZX-40/6 | 40 | 17 | 40 | 6.67 | 46.7 | 6 | 1 | 2.91 | 2.91 | 2.91 | 2.91 | 14.4 | 13.93 | 13.93 | 15.33 | 14.87 | | NZX-65/10 | 63 | 17 | 63 | 10.5 | 73.5 | 6 | 1 | 3.66 | 3.66 | 3.66 | 3.66 | 21.63 | 20.58 | 20.58 | 22.37 | 21.63 | | NZX-100/17 | 100 | 17 | 100 | 16.8 | 117 | 6 | 1 | 4.61 | 4.61 | 4.61 | 4.61 | 34.33 | 32.67 | 32.67 | 35.50 | 34.33 | | NZX-125/7 | 125 | 6 | 125 | 6.94 | 132 | 18 | 1 | 2.97 | 2.97 | 2.97 | 14.9 | 29.17 | 28.68 | 28.68 | 30.14 | 29.65 | | NZX-125/20 | 125 | 16 | 125 | 20.4 | 145 | 26 | 1 | 2.47 | 1.92 | 5.77 | 15.7 | 45.69 | 44.27 | 44.27 | 48.54 | 47.12 | | NZX-160/9 | 160 | 6 | 160 | 8.89 | 169 | 18 | 7 | 3.36 | 3.36 | 3.36 | 16.8 | 36.18 | 35.29 | 35.29 | 37.42 | 36.80 | | NZX-160/26 | 160 | 116 | 160 | 26.1 | 186 | 26 | 1 | 2.80 | 2.18 | 6.53 | 17.7 | 57.69 | 55.86 | 55.86 | 61.34 | 59.51 | | NZX-200/11 | 200 | 6 | 200 | 11.1 | 211 | 18 | 7 | 3.76 | 3.76 | 3.76 | 18.8 | 44.22 | 43.11 | 43.11 | 45.00 | 44.22 | | NZX-200/32 | 200 | 16 | 200 | 32.6 | 233 | 26 | 1 | 3.13 | 2.43 | 7.30 | 19.8 | 70.13 | 67.85 | 67.85 | 74.69 | 72.41 | | NZX-250/25 | 250 | 10 | 250 | 24.6 | 275 | 22 | 7 | 3.80 | 2.11 | 6.34 | 21.6 | 68.72 | 67.01 | 67.01 | 72.16 | 70.44 | | NZX-250/40 | 250 | 16 | 250 | 40.7 | 291 | 26 | 7 | 3.50 | 2.72 | 8.16 | 22.2 | 87.67 | 84.82 | 84.82 | 93.37 | 90.52 | | NZX-315/22 | 315 | 7 | 315 | 21.8 | 337 | 45 | 7 | 2.99 | 1.99 | 5.97 | 23.9 | 78.03 | 77.51 | 77.51 | 82.08 | 80.55 | | NZX-215/50 | 315 | 16 | 315 | 51.3 | 366 | 26 | 7 | 3.93 | 3.05 | 9.16 | 24.9 | 106.83 | 101.70 | 101.70 | 114.02 | 110.43 | | NZX-400/28 | 400 | 7 | 400 | 27.7 | 428 | 45 | 7 | 3.36 | 2.24 | 6.73 | 26.9 | 98.36 | 96.42 | 96.42 | 102.23 | 100.29 | | NZX-400/50 | 400 | 13 | 400 | 51.9 | 452 | 54 | 7 | 3.07 | 3.07 | 9.21 | 27.6 | 123.04 | 117.85 | 117.85 | 130.30 | 126.67 | | NZX-450/30 | 450 | 7 | 450 | 31.1 | 481 | 45 | 7 | 3.57 | 2.38 | 7.14 | 28.5 | 107.47 | 105.29 | 105.29 | 111.82 | 109.64 | | NZX-450/60 | 450 | 13 | 450 | 58.3 | 508 | 54 | 7 | 3.26 | 3.26 | 9.77 | 29.3 | 138.42 | 132.58 | 132.58 | 146.58 | 142.50 | | NZX-500/35 | 500 | 7 | 500 | 34.6 | 535 | 45 | 7 | 3.76 | 2.51 | 7.52 | 30.1 | 119.41 | 116.99 | 116.99 | 124.25 | 121.93 |
| 注：型號中字母與數字意義; N-耐張線夾 ; Z-直通; X-楔形; |
|
|
